Turnstile
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE**
**EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V**
Key Features:
Electrical Controls for Both Directions
Push Button Switch Override Controls for Emergency Situations
Heavy-duty High Precision Mechanism
Mechanism Designed not to lock at 45°
Modular Assembly Provides for Moving Turnstile
Self Centering Mechanism to ensure complete rotation of the head to the rest position
Automatic Reset Function
Anti-tailing Function
Selectable Operating Modes: Single Direction, Bi-Direction
Anti-reverse Function
Stainless Steel AISI 304/AISI316
Integration with any Card/Biometric Reader
Specifications:
Dimensions
1400(W) x 2310(H) x 1200(D) mm
Passage Width
≤650
Throughput Rate
30 person/min
Material
Stainless Steel 304
Unlock Time
0.2 s
Power Supply
100V ~ 240V
Motor Voltage
24V
Temperature
-27 °C ~ 70 °C
Power Consumption
30W
*Specifications are subject to change without notice
*Terms and conditions apply
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE** **EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V** Key Features: Electrical Controls for Both Directions Push Button...
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE**
**EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V**
Key Features:
Infrared Sensors and Anti-illegal Entry Function
Double Anti-clipping Function
Automatic Reset Function
LED Passage Indicator
Selectable Operating Modes: Single Direction, Bi-Direction, Free Passage
Stainless Steel 304
Integration with any Card/Biometric Reader
Specifications:
Dimensions
120(W) x 980(H) x 1500(D) mm
Passage Width
600-900 mm
Throughput Rate
35 person/min
Material
Full 12mm Black Acrylic +1.2mm SUS304
Unlock Time
0.1 s
Power Supply
100V ~ 240V
Motor Voltage
24V
Temperature
-25 °C ~ 70 °C
Power Consumption
35W
*Specifications are subject to change without notice
*Terms and conditions apply
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE** **EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V** Key Features: Infrared Sensors and Anti-illegal Entry Function Double...
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE**
**EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V**
Key Features:
LED Passage Indicator
Easy to Operate
Selectable Operating Modes: Single Direction, Bi-Direction, Free Access, Locked
Automatic Reset Function
Stainless Steel AISI 304/AISI316
Integration with any Card/Biometric Reader
Specifications:
Dimensions
280(W) x 980(H) x 1200(D) mm
Passage Width
≤900
Throughput Rate
35 person/min
Material
Stainless Steel AISI 304 / AISI316
Unlock Time
0.2 s
Power Supply
100V ~ 240V
Motor Voltage
24V
Temperature
-25 °C ~ 70 °C
Power Consumption
35W
*Specifications are subject to change without notice
*Terms and conditions apply
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE** **EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V** Key Features: LED Passage Indicator Easy to Operate Selectable...
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE**
**EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V**
Key Features:
With voice and strobe light alerts
Double anti-clipping function, photocell anti-clipping and mechanical anti-clipping
Auto re-set function
Can set delay closing from 1-60 seconds
SPECIFICATIONS:
DIMENSIONS
185(W) X 1020(H) X 1400(D) MM
PASSAGE WIDTH
≤900
THROUGHPUT RATE
35 PERSON/MIN
MATERIAL
STAINLESS STEEL 304
UNLOCK TIME
0.2 S
POWER SUPPLY
100V ~ 240V
MOTOR VOLTAGE
24V
TEMPERATURE
-25 °C ~ 70 °C
POWER CONSUMPTION
35W
*Specifications are subject to change without notice
*Terms and conditions apply
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE** **EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V** Key Features: With voice and strobe light alerts Double...
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE**
**EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V**
Key Features:
Single passage in the set direction
Bi-directional single passage
Free passage in the set direction
Capable of fully unlocked/locked passage
Customizable
SPECIFICATIONS:
DIMENSIONS
200(W) X 980(H) X 1100(D) MM
PASSAGE WIDTH
≤1100
THROUGHPUT RATE
30-35 PERSON/MIN
MATERIAL
STAINLESS STEEL 304
UNLOCK TIME
0.2 S
POWER SUPPLY
100V ~ 240V
MOTOR VOLTAGE
24V
TEMPERATURE
-25 to +70 ℃
POWER CONSUMPTION
35W
*Specifications are subject to change without notice
*Terms and conditions apply
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE** **EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V** Key Features: Single passage in the set direction Bi-directional...
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE**
**EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V**
Key Features:
Automatic Reset Function
Anti-tailing Function
LED Passage Indicator
Selectable Operating Modes: Single Direction, Bi-Direction
Anti-reverse Function
Stainless Steel 304
Integration with any Card/Biometric Reader
Specifications:
Dimensions
280(W) x 990(H) x 1200(D) mm
Passage Width
≤550
Throughput Rate
30 to 40 person/min
Material
Stainless Steel 304
Unlock Time
0.2 s
Power Supply
100V ~ 240V
Motor Voltage
24V
Temperature
-40 °C ~ 70 °C
Power Consumption
20W
*Specifications are subject to change without notice
*Terms and conditions apply
**INSTALLATION WORKS & COMMISSIONING INCLUSIVE** **EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V** Key Features: Automatic Reset Function Anti-tailing Function LED Passage...
Turnstile
Having a turnstile within your company is a great way to ensure that unregistered or unwelcome visitors are prohibited from entering your property. We offer a number of high-quality turnstiles, all of which can be carefully installed by our team of professionals. Turnstile are fantastic for use at all corporate buildings as well as leisure companies such as swimming pools and gyms. They can only be accessed by using a pin or keycode that you have set for a particular employee. This can be done through the creation of an account, which you can then monitor as you wish.
We understand that an unwanted visitor in the workplace can cause significant harm and/or disruption to the workplace. By installing a turnstile, you can add that extra layer of protection, providing your security team with the time they need to react and deal with the situation before it is able to unfold. Once installed, our team will provide you with a comprehensive manual on how the turnstile operates and how you can edit the settings to best suit your company. If you experience any problems, our team are available via telephone or email to provide you with a range of different solutions. Do visit our blog for more information.
