**INSTALLATION WORKS & COMMISSIONING INCLUSIVE**
**EXCLUDED BUILDERS & CONSTRUCTION WORKS, AC230V**
Key Features:
- Electrical Controls for Both Directions
- Push Button Switch Override Controls for Emergency Situations
- Heavy-duty High Precision Mechanism
- Mechanism Designed not to lock at 45°
- Modular Assembly Provides for Moving Turnstile
- Self Centering Mechanism to ensure complete rotation of the head to the rest position
- Automatic Reset Function
- Anti-tailing Function
- Selectable Operating Modes: Single Direction, Bi-Direction
- Anti-reverse Function
- Stainless Steel AISI 304/AISI316
- Integration with any Card/Biometric Reader
Specifications: |
|
Dimensions |
1400(W) x 2310(H) x 1200(D) mm |
Passage Width |
≤650 |
Throughput Rate |
30 person/min |
Material |
Stainless Steel 304 |
Unlock Time |
0.2 s |
Power Supply |
100V ~ 240V |
Motor Voltage |
24V |
Temperature |
-27 °C ~ 70 °C |
Power Consumption |
30W |
*Specifications are subject to change without notice
*Terms and conditions apply
